Low-pressure precision filter gland filter air processing capacity from 1m3-30m3, from general to precision to ultra-precision, and activated carbon filters.

法兰式精密过滤器参数

型号		YDF-	YDF-	YDF-	YDF-	YDF-	YDF-	YDF-	YDF-	YDF-	YDF-	YDF-	YDF-	YDF-
型号		1	2	3	6	12	20	30	40	60	80	100	150	200
额定处理量		1	2	3	6	12	20	30	40	60	80	100	150	200
进出口通径 DN-MM		20	25	40	40	50	65	80	100	100	125	150	200	250
外形尺寸	气口间距	150	190	200	220	220	400	450	450	500	550	650	650	800
mm	高度	580	650	680	820	930	1250	880	1250	1250	1250	1250	1250	1250
